Construction
Frame section 115x60 mm on 3 sides and 84x80 mm in the lower crosspiece.
Isos
With Isos the concept of window and door is redefined, for an even brighter design. The full glass concept frames the outdoors in all their beauty, without adding filters. Its technical features, with a completely recessed wooden frame, in addition to emphasizing its aesthetics, allow excellent performance from all points of view (air, water, thermal and acoustic tightness) for well-being, safety and silence without compromise. A solution that combines wood with external aluminum profiles on 4 sides. A solid structure with strong technical and aesthetic features to enhance contemporary architecture.
Hardware
External aluminum profiles on 4 sides and on the lower side of the internal side, internal glass stops in various woods and finishes.
Glass
Double glazing 44.2/20/33.1 low emissivity 1.0 with argon gas and Super Spacer spacer channel (Ug=1.1 W/m2K). Double chamber 44.2 low emissivity/20/4/20/33.1 low emissivity with argon gas and Super Spacer spacer channel (Ug=0.5 W/m2K).
Finishes
Painting with a water cycle with a natural or colored anti-mold and anti-woodworm impregnator applied with a flow-coating system with multiple finishing coats. The paints used have a low environmental impact.
A+
Energy index
4
Air permeability
0,6W/m2k
Thermal insulation calculated on frame dimensions 2000 x 2400 mm
44%
Glass solar factor up to
72%
Light transmission up to
51dB
Acoustic insulation glass up to
WK2
Hardware with installation option
